QuicRun WP 10BL60 G2
QuicRun WP 10BL60 G2
Intelligent freewheeling
technology effectively
reduces heat generation
The intelligent freewheeling technology enables
the ESC to be able to achieve higher driving efficiency
at a lower operating temperature.
It further improves on the stability
and reliability of the ESC.
Small and compact
The new QuicRun WP 10BL60 ESC is more
compact than its predecessor
It is shorter in length by
2.5mm

The width is reduced by
1.5mm


Overall, it makes the
layout and wiring convenient

Efficient cooling system
The mesh design of the heat sink is used
for efficient cooling of the ESC.
Each of the phases adapt a copper
thermal bar for better cooling.
The heat sink designed with the fan ensures
the ESC is always in the best operating temperatures.
Capacitor overheating protection
The capacitor overheating protection function will effectively
prevent exploding capacitors due to overload usage.
It prevents users from completely damaging the ESC.
All-weather operation capability
The ESC's protection level reaches IP67.
Able to easily cope with various competition environments such as rain,
dust, and sand with its excellent waterproof and dust-proof protection.
Note
The above-mentioned IP67 protection level is splash-proof, water-resistant, and dust-proof under normal use.
It is not permanently effective, and the protective performance may degrade due to daily wear and aging.
Do not submerge in water for a long time, otherwise the product may be damaged.
A vast variety of
programming methods
It supports three programming methods:
Multi-function LCD programming box PRO, LED programming box, and SET key,
making it easy for users to choose their favorite
programming method for parameter adjustment.
  • LCD programming box PRO
  • LED programming box
  • SET key
Great value for money
Designed specifically for entry-level users.
Simple to use high quality product. Easy to install and go!
Product Name
QuicRun WP 10BL60 G2
Product Number
  30107300
Type
Scale 1/10th
Brushed/Brushless Brushless
Sensored/Sensorless Sensorless
Waterproof Waterproof
Specifications
Cont./Peak Current 60A/360A
Input Voltage 2-3S Lipo
BEC BEC Output Switch Mode 6V @3A
Wires & Connectors
Input Wires Black-14AWG-150mm*1 Red-14AWG-150mm*1
Output Wires Black-14AWG-60mm*3
Input Connectors No
Output Connectors 4.0MM Gold (female)
Fan
Size 30.0x30.0x10.0mm
Voltage Range 6V
Powered by BEC
ESC Programing via
SET Button on ESC Supported
LED Program Box Supported
LCD G2 Program Box Supported
LCD PRO Supported
OTA Programmer Not Supported
Program Port Shared with fan port
Data Recording
Extreme value Not Supported
Real-time Data Not Supported
Historical data (Graph) Not Supported
Firmware
Firmware Upgrade Not Supported
Size & Weight
Size 46*36.5*34.3mm
Weight 82.6g (Included wires&connectors)
Applications
Motors Sensorless / Sensored Brushless Motor (only in sensorless mode)
Vehicles 1/10th On-road,Buggy,Short course truck
KV Rating/T Count 2S LiPo:KV≤6000；3S LiPo:KV≤3500（3652/3660 size motor）
Support

Manuals & Documents

Manuals

FAQ

LED Program Box_General

LED Program Box_General

Part Number: 30501003
Size: 88x58x14mm（LxWxH）
Applications:
Platinum V1/V2 series & FlyFun V5 SkyWalker V2
Series of brushless aircraft ESCs
XeRun series (most), EzRun series
& QuicRun series of brushless car ESCs
SeaKing series of brushless boat ESCs

+
LCD Program Box Pro

NEW

LCD Program Box Pro

Product Number: 30502002
Input Voltage: DC 5V~12.6V
Application: brushless ESC
Weight: 85g
Display:LCD

+
