XeRun AXE PLUS R3
6S high-power crawler ESC
  • The ESC supports up to
    6S LiPo bttery.
  • It has a maximum output
    continuous current of up to
    135A.
  • The AXE R3 can be used on
    1/10th and 1/8th crawler,
  • also compatible with
    1/7th and 1/6th crawler.
  • New compact design.
  • Compatible with all
    Axe R2 motors.
  Note: The AXE R3 is 2.1mm longer, 1.7mm wider and 3.7mm shorter than the R2 ESC.
Dual external control
channels, real-time
adjustment of parameters
Connect the white and yellow signal cables to open channels of
the receicver to adjust parameters in real time.
  Note: The actual functions of the white and yellow wires correspond to the setting
parameters of channel 3/4 in the parameter table respectively.
FOC drive, linear,
with plenty torque,
and very quite
The XeRun AXE R3 is equipped with a FOC drive system.
The large torque and excellent linearity when operating
at low speed further exceeds ordinary brushless power
systems and out performs brushed power systems.
The XeRun AXE R3 is nearly silent, and it’s the perfect choice
for crawling vehicles.
Smart torque output,
easy to control
The ESC automatically increases the torque output to overcome resistance
and accelerate up the hill. Vice versa, the ESC automatically reduces the
torque output and stabilizes the vehicle speed when going down the hill.
Provides excellent control going Up, or Down hills.
The ESC is powerful, with excellent linear control,
which can meet the needs of the vehicle's low-speed
climbing while also meeting the needs of violent
start-up lifting, straight-line high speed, etc.
Smart fan start
and stop function
The fan starts to operate automatically ONLY
when the ESC temperature reaches the preset value.
The smart start and stop function of the fan helps to save power,
reduce noise, and also ensures that
the ESC works in a good temperature range.

High protection level
The AXE R3 brushless system is now IP67 protected.
It has excellent waterproofing and dust-proofing performance
to cope with various climatic conditions.
  Note:
The above-mentioned IP67 protection level is splash-proof,
water-resistant, and dust-proof under normal use.
It is not permanently effective, and the protective performance
may decrease due to aging.
Do not submerge in water for a long time,
otherwise the product may be damaged.
Super Internal BEC
It has a built-in powerful BEC with a maximum output current of 15A.
The voltage is switchable between 6V/7.4V/8.4V
and is suitable for various standard/high-voltage servos
and peripheral electrical equipment on the market (such as light sets, winches, etc.).
Built-in Bluetooth for
Connecting the
Mobile APP Directly
The ESC has a built-in Bluetooth module.
Parameter settings, data reading, firmware upgrade
and other operations can be achieved
by connecting the device to the mobile APP.
Obtain AXE Running
Status with
Real-time Data
Function with ease
Connect the ESC to the HW Link mobile app and
turn on the real-time data function.
You are able to view throttle, voltage, current, temperature, speed
and other data in real time, and obtain the ESC
and motor operating status with ease.
  Note: The effective distance is only about 5m due to
transmission distance of bluetooth.
Built-in data logging function,
ease of obtaining power
operating status
The ESC has a built in data rcoerdind module. Store up to 10 minutes
of your most recent run. Using the HW Link V2saved to the ESC.
saved to the ESC. In addition,the module allows you to view Time
Data from the ESC for bench top testing and viewing of the data outputs.
Note: Due to transmission distance of bluetooth, the effective distance is only about 5m!
Compatible with
AXE R2 motor
AXE R3 ESC supports both AXE 4274 R3 motor
and AXE 550/540L/540 R2 motor.
  Note: AXE R2 motor, 2800KV/2100KV/1400KV/2300kv
are recommended to use 3-4S.
Supports Flysky
i-BUS2 Telemetry
Achieve real-time ESC parameter adjustments
using the I-BUS2 Telemetry on the Flysky NB4 controllers.
Additionally, the data return function has been
implemented to the Flysky NB4 remote controllers.
You will be able to view data such as;
battery voltage, motor speed, operating current,
ESC/motor temperature, etc in real time on the remote control.

Note: You are required to upgrade to the latest firmware on your remote control
in order to use the Ibus2 functions.
A vast variety of parameters
The XeRun AXE R3 has a vast variety of parameters for adjustment.
It has a total of 21 adjustable parameters and supports 24-degree adjustable Turbo timing.
The maximum speed can be unleashed with good road conditions.
Product Name
XERUN AXE PLUS R3
Product Number
  30113201
Type
Scale 1/10th,1/8th,1/6th
Brushed/Brushless BL
Sensored/Sensorless SD
Waterproof Waterproof
Specifications
Cont./Peak Current 135A/600A
Input Voltage 2-6S Lipo
BEC BEC Output Switch Mode 6V/7.4V/8.4V @6A
Wires & Connectors
Input Wires Black-12AWG-265mm*1 Red-12AWG-265mm*1
Output Wires NO
Input Connectors XT60
Output Connectors No
Fan
Size 25*25*10mm
Voltage Range 6-8.4V
Powered by BEC
ESC Programing via
SET Button on ESC Not Supported
LED Program Box Not Supported
LCD G2 Program Box Not Supported
LCD PRO Not Supported
OTA Programmer Not Supported
Program Port Built-in bluetooth
Data Recording
Extreme value Supported
Real-time Data Supported
Historical data (Graph) Supported
Firmware
Firmware Upgrade Supported
Size & Weight
Size 49.5*37.9*32.8mm(Height with fan)
Weight 126.5g(Including the weight of input line)
Applications
Motors Only support XERUN AXE R2/R3 motor
Vehicles 1/10th,1/8th,1/6th Rock Crawler
KV Rating/T Count AXE R2 540/540L/550
AXE R3 4274
