MP-Matt Pro
Carbon Fiber Straight Propeller
-
RC Systems
RC Cars Power SystemRC Plane Power SystemRC Boat Power SystemAccessories
-
Drone Systems
-
- INTEGRATED PROPULSION SYSTEM Innovation and Performance for a simplified assembly.
- X Series
- H Series
-
-
-
- PROPELLER Superior efficiency, exceptional stability.
- Carbon Plastic Propeller
- Carbon Fiber Propeller
-
- WATER PUMP Minimal maintenance, long service life.
- 5L
- 8L
-
-
-
Personal Travel Systems
Electric SkateboardElectric ScooterPersonal Travel Accessories
- Service and Support
Elaborate industry-specific
propeller with
versatile applicability
propeller with
versatile applicability
Superior performance
high efficiency and stability
high efficiency and stability
Long service life, high outdoor adaptability, and enhanced efficiency
and stability make it suitable for the long-endurance operation of industrial drones;
the dynamic balancing test technology ensures accurate vibration control during operation.
and stability make it suitable for the long-endurance operation of industrial drones;
the dynamic balancing test technology ensures accurate vibration control during operation.
- Model
Weight
Recommended speed range
Ultimate tension
Recommended thrust - MP 16×5.4"
25 g
4000~6500 r/min
7.0 kg
1.4~3.0 kg - MP 17×5.8"
32 g
4000~6500 r/min
8.0 kg
2.0~4.0 kg - MP 18×6.1"
35 g
3500~6000 r/min
8.5 kg
2.0~4.2 kg - MP 19×5.7"
41 g
3000~5500 r/min
9.0 kg
2.0~4.2 kg - MP 20×6.0"
46 g
3000~5500 r/min
10.0 kg
2.5~4.5 kg - MP 21×6.3"
47 g
3000~5500 r/min
11.0 kg
2.5~4.5 kg
Elevate performance to
new heights with
HOBBYWING’s H series motor
new heights with
HOBBYWING’s H series motor
The dynamic performance of the entire propulsion system is fully played by
using propellers with the HOBBYWING’s H series motor with an elaborate magnetic circuit.
using propellers with the HOBBYWING’s H series motor with an elaborate magnetic circuit.
Recommended Combinations
- Model
Recommended motors - MP 16×5.4"
M4006/V5212 - MP 17×5.8"
M4006/M5208/V5212 - MP 18×6.1"
M5208
- Model
Recommended motors - MP 19×5.7"
M5208 - MP 20×6.0"
M5208 - MP 21×6.3"
M5208/M6215
Easy installation
The propellers can be installed by
direct locking of motor rotor and quick dismantling of propeller base.
direct locking of motor rotor and quick dismantling of propeller base.
MP 16x5.4" CAD
MP 16x5.4" Load performance parameters
MP 17x5.8" CAD
MP 17x5.8" Load performance parameters
MP 18x6.1" CAD
MP 18x6.1" Load performance parameters
MP 19x5.7" CAD
MP 19x5.7" Load performance parameters
MP 20x6.0 " CAD
MP 20x6.0" Load performance parameters
MP 21x6.3" CAD
MP 21x6.3" Load performance parameters
MP 54x20" CAD
MP 54x20" Load performance parameters
MP 57x20" CAD
MP 57x20" Load performance parameters
