Low-impedance Capacitor Module

Low-impedance Capacitor Module

Overview

This capacitor module (/cappack) is for “upgrading” your car ESC. With this cappack, the start-up acceleration of your vehicle will be greatly improved. Besides, the great ripple current endurance significantly reduces the generated interference due to the rapid ON/OFF of the ESC power tube.

Features

Low impedance, low heat generation, great start-up acceleration. The comparison between HobbyWing capacitor module and some famous capapack.

Brand

HobbWing

Some Famous Brand

Internal Resistance

0.002Ω

0.012Ω

Ripple Current Endurance

24Amp

3.5Amp

With the great ripple current endurance, the interference generating from turning on/off of your ESC power tube is remarkably reduced.
With the small size and light weight, it’s easy to install.

Accessories for “Upgrading” ESCs

Items


Paramete

1

PN:86030030
Product Name: STD-CAPACITORS MODULE-D
Specifications: Cappack for Car ESC(s)-XERUN (560u/20V *2PCS)
Applications: XERUN XR10 PRO,XERUN XR10 STOCK SPEC,XERUN-120A-V3.1/V2.1 , XSTOCK ,QUICRUN-10BL60-SENSORED etc.

2

PN:86030000
Product Name: UPGRADE-CAPACITORS MODULE-A
Specifications: Cappack for Car ESC(s) - Upgrade
Applications: XERUN XR10 PRO,XERUN XR10 STOCK SPEC,XERUN-120A-V3.1/V2.1 , XSTOCK ,QUICRUN-10BL60-SENSORED etc.

3

PN: 30840000
Product Name: STD-CAPACITORS MODULE-E
Specifications: Cappack for Car ESCs (470u/35V*4PCS)
Applications: XERUN XR8-Plus, EZRUN MAX8, QUICRUN-WP-8BL150
