EzRun 2030

Construction

The motor housing is made from hard anodized aluminum, motor windings are wound
from double insulated wire, the advanced rotor structure is designed to handle high
temperature from the use of rare earth magnets and the bearings which are implemented are
high precision metal caged for a minimum to zero friction which
in turn will guarantee strength, outstanding performance,
high durability and smoothness of the motor.

Construction

High Efficiency

The output performance of this motor has an efficiency of up to 85%.
In the same load condition, EZRUN 2030 has the higher efficiency but lower
temperature than other 2030 motors.

High Efficiency

Plug and Play

Pre-soldered with high-quality gold connectors on motor leads,
the EZRUN 2030 motor is definitely a plug and play.

Plug and Play

Plug and Play

Wide Application

The EZRUN 2030 is applicable to various 1/16th & 1/18th scale vehicles, especially buggies.

Wide Application

1/18th SCT

1/18th buggies

1/16th  Monster Truck

Product Name
Product Number
Type Scale

Brushed/Brushless

Sensored/Sensorless

Pole Count
Relevant Parameters KV Rating

LiPo Cells

Size & Weight O.D.(mm)

Length (mm)

Shaft Diameter (mm)

Connectors (mm)

Weight (g)
Other Parameters Timing

Applications
Product Name EzRun 2030-12T EzRun 2030-18T
Product Number 90010000 90010010
Type Scale

Brushed/Brushless

Sensored/Sensorless

Pole Count
1/16th, 1/18th

BL

SL

2
1/16th, 1/18th

BL

SL

2
Relevant Parameters KV Rating

LiPo Cells

7800

2S
5200

2S
Size & Weight O.D.(mm)

Length (mm)

Shaft Diameter (mm)

Connectors (mm)

Weight (g)
20.0

30.0

2.0

3.5(male)

46
20.0

30.0

2.0

3.5(male)

46
Other Parameters Timing

Applications
0

1/16th, 1/18th Touring Card, Buggies
0

1/16th, 1/18th Touring Card, Buggies

FAQ

EzRun 2030

Construction

The motor housing is made from hard anodized aluminum, motor windings are wound from double insulated wire, the advanced rotor structure is designed to handle high temperature from the use of rare earth magnets and the bearings which are implemented are high precision metal caged for a minimum to zero friction which in turn will guarantee strength, outstanding performance, high durability and smoothness of the motor.

Construction

High Efficiency

The output performance of this motor has an efficiency of up to 85%. In the same load condition, EZRUN 2030 has the higher efficiency but lower temperature than other 2030 motors.

High Efficiency

Plug and Play

Pre-soldered with high-quality gold connectors on motor leads, the EZRUN 2030 motor is definitely a plug and play.

Plug and Play

Wide Application

The EZRUN 2030 is applicable to various 1/16th & 1/18th scale vehicles, especially buggies.

Wide Application

Product Name EzRun 2030-12T
Product Number 90010000
Type Scale

Brushed/Brushless

Sensored/Sensorless

Pole Count
1/16th, 1/18th

BL

SL

2
Relevant Parameters KV Rating

LiPo Cells

7800

2S
Size & Weight O.D.(mm)

Length (mm)

Shaft Diameter (mm)

Connectors (mm)

Weight (g)
20.0

30.0

2.0

3.5(male)

46
Other Parameters Timing

Applications
0

1/16th, 1/18th Touring Card, Buggies
Product Name EzRun 2030-12T EzRun 2030-18T
Product Number 90010000 90010010
Type Scale

Brushed/Brushless

Sensored/Sensorless

Pole Count
1/16th, 1/18th

BL

SL

2
1/16th, 1/18th

BL

SL

2
Relevant Parameters KV Rating

LiPo Cells

7800

2S
5200

2S
Size & Weight O.D.(mm)

Length (mm)

Shaft Diameter (mm)

Connectors (mm)

Weight (g)
20.0

30.0

2.0

3.5(male)

46
20.0

30.0

2.0

3.5(male)

46
Other Parameters Timing

Applications
0

1/16th, 1/18th Touring Card, Buggies
0

1/16th, 1/18th Touring Card, Buggies

FAQ
