E-Scooter ESC

E-Scooter ESC

Overview

Ultra-high reliability

The product adopts the full filling process to isolate erosion from sewage and dust. The waterproof, dustproof and shockproof protections help to prolong the lifespan of the product.

FOC Drive mode

As an industry leader, the whole series adopts FOC drive scheme and can perfectly support Hall-free Zero-speed start.

Self-learning function

The product supports self-learning function. It automatically detects the motor parameters through simple operation to simplify the difficulty of sample adaptation, and overcomes the debugging cycle problem.

Fail-safe function

Rich and detailed self-protection functions including; throttle protection, brake protection, high and low voltage protection, communication fault protection, motor fault protection, overheating protection and etc. Maximum protection of the controller for driving safety.

Support a variety of peripherals

We have developed a variety of controllers for different models to support signal directions, headlights/tail lights of various voltages, and ambient lights driven by conventional or SPI chips. At the same time, for batteries with BMS chips, IoT devices from multiple manufacturers have corresponding controller support.

Complete product line

Products from 5S (18V) -16S (60V) voltage of the battery cells are adapted. The maximum sustained current of up to 50A (single motor), covering the vast majority of two-wheeled scooters and electric mopeds.



OTA upgrade supported

Upgrading of firmware can be achieved through the official APP: UNI SCOOTER. Users are able to enjoy the latest features or debug faulty issues.



Specifications




Model: 9044 9059 9037 9054 9058
Operating voltage: 36/48V 48/52/60V 36/48V 48/52V 48/52/60V
Maximum continuous current: 20A 30A(48/52V) ; 25A(60V) 18A×2 30A×2 50A×2
Size/mm: 80*61*25 106*64*23 92*68*20 135*80*25 141*96*25
Weight/g: 185 153 292 406 521
Full glue assembly process:
Meter supply voltage: 12V/VBAT 12V/VBAT 12V 12V/VBAT 12V/VBAT
Head light interface:
Tail light connector:
Signal light connector:
SPI ambient light interface: \
Sensorless operation:
IoT support: \ \ \ \
BMS support: \
IP65 waterproof level:
Motor adaptive learning:
Application: E-Scooter
