EzRun MAX5 HV G2
EzRun MAX5 HV G2
Brushless Electronic Speed Controller
12S HV ESC, enhanced performance
The Max5 HV G2 ESC is designed to work in full-sensored mode at all times when it
is paired with HOBBYWING EZRUN 56118 G2. The ESC supports up to 12s Lipo
with a maximum output current of up to 250A. The strong explosive,
stable output power, together with an excellent low-speed linearity,
ensures the ESC meets various application requirements such as;
violent start-up,straight-line high-speed, flying slopes, low-speed walking, etc.
Intelligent freewheeling technology,
strong drive low temperatures
The innovative intelligent freewheeling technology effectively
reduces heat generation and enables the ESC to have higher
driving efficiency. With the addition of super-high power design,
operating temperature is drastically lowered (approximately 30 degrees)
to improve overall stability and reliability of the ESC.
Note: Under heavy load conditions, the temperature of MAX5 HV G2 is only slightly higher than that of MAX4 HV.
High protection level, all-weather operation
The IP-67 waterproof rating guarantees excellent waterproof and dustproof protection.
The whole power system is able to drive on a variety of surfaces including mud,
sand, ice, snow and water without damaging the power unit.
Note: The IP67 protection level mentioned above is splash-resistant, water-resistant and dust-resistant under normal use,
and splash, water and dust resistance are not permanently effective, and the level of protection may decline due to aging.
Do not soak for a long time to avoid damaging the product.
1/5th scale power system Turbo timing technology
The ESC is able to support up to 24 degrees of Turbo Timing adjustment.
There is an approximate of increase in performance and
is recommended to pair with the new HOBBYWING EzRun 56118 SD G2
motors to get the best performance.
Note: For non-Hobbywing EzRun 56118 G2 motors, Turbo timing cannot be turned on
Capacitor upgrade,
more secure protection
Compared with the previous generation (MAX5 ESC),
the total capacity of the capacitor has increased by 45% (1260uF).
The super large capacity ensures that 5th scale models
do not need external capacitors. In addition,
the built-in capacitor thermal protection function of
the ESC is always in safe operating state.
EzRun MAX5 HV G2
The total capacitance of the capacitor has increased by
45%

EzRun MAX5

Powerful BEC
The ESC has a built-in super BEC with a maximum output current of up to 25A.
The output voltages are switchable between 6V/7.4V/8.4V.
This ensures that the ESC is able to support the
demanding high-torque servos in the market.

  • with a maximum output
    current of up to
    25A

  • The output voltages are
    switchable between
    6V/7.4V/8.4V

Built-in anti-spark design,
multi-directional protection
The ESC has a built-in anti-spark circuit to protect
the battery plug from damaging upon ucsing
a higher voltage battery(6-12S),
and avoids any injuries.
Perfect combination with
EZRUN 56118 SD G2 motor
Achieve the perfect compatibility when used together with EzRun 56118 SD G2 motors.
Avoid damaging the motor from overheating with the software protection function.
Note: Non-Hobbywing EzRun 56118 SD G2 motors cannot realize motor overheat protection
Record and store data in
real time to keep track
of the running status
Connect the ESC to the OTA Bluetooth module,
and through the mobile phone APP,
you are able to view real-time data and operating status such as;
throttle, voltage, current, temperature, speed, etc.
Note: Due to the Bluetooth transmission distance,
the effective distance is only about 5m!
New sensor wire interface,
upgraded waterproof protection
The new sensor wire interface enhances the ESC protection level
and solves waterproof problems faced by traditional interfaces.
Please Note: This ESC supports sensored motors with common interfaces.
Sensor wire needs to be purchased separately!
Product Name
Product Number
Type Scale

Brushed/Brushless

Sensored/Sensorless

Waterproof
Specifications Cont./Peak Current

Input Voltage

BEC Output
Wires & Connectors Input Wires

Input Connectors
ESC Programing via SET Button on ESC

LED Program Box

LCD Program Box

OTA Programmer

Program Port
Fan Size

Output Wires

Input Connectors
Data Recording Extreme value

Real-time Data

Historical data (Graph)
Firmware Firmware Upgrade
Size & Weight Size

Weight
Applications Motors

Vehicles

Product Name EZRUN MAX5 HV G2
Product Number 30104200
Type Scale

Brushed/Brushless

Sensored/Sensorless

Waterproof		 1/5th

BL

SD

Yes
Specifications Cont./Peak Current

Input Voltage

BEC Output		 250A/1600A

6-12S Lipo

6V/7.4V/8.4V adjustable, continuous current 8A (Switch-mode)
Wires & Connectors Input Wires

Input Connectors		 Black-8AWG-200MMmm*1/Red-8AWG-200MMmm*1

8.0mm Bullet Connectors (Female)
ESC Programing via SET Button on ESC

LED Program Box

LCD Program Box

OTA Programmer

Program Port		 Not Supported

Supported

Supported

Supported

Independent programming port
Fan Size

Output Wires

Input Connectors		 45x45x10mm

5-8.4V

Powered by BEC
Data Recording Extreme value

Real-time Data

Historical data (Graph)		 Supported(LCD)

Supported

Supported
Firmware Firmware Upgrade Supported
Size & Weight Size

Weight		 94.5*59.4*52.1mm

428.5g (Included input wires)
Applications Motors

Vehicles

56118 size motors

1/5th Truck,Buggy

Examples: Losi DBXL-E、 Losi 5T Electrified、ARRMA Kraton 8S、ARRMA Outcast 8S
Support

Manuals & Documents

Manuals

Software Download

FAQ

Multifunction LCD Program Box

Multifunction LCD Program Box

Part Number: 30502001
Size: 91x51x17mm (LxWxH)
Applications: Platinum series of
brushless aircraft ESCs, XeRun
series & EzRun series of brushless
car ESCs, SeaKing Pro series of
brushless boat ESCs

+
OTA Programmer

OTA Programmer

Product Number: 30850400
Working Voltage: 5-12.6V
Supported Bluetooh Version: ≥ 4.0
Effective Range: 0-5m (Open Field)
Applications: work on the XzRun series,
EzRun series of car ESCs, and the Platinum
series of aircraft ESCs, and
Seaking Prp series of boat ESCs.

+
